WG Series Pulse Vacuum Autoclave
This series of WG Series Pulse Vacuum Autoclave utilizes saturated steam as its sterilization medium which releases a large amount of heat in the stage of condensation, and ensure the sterilizing environment.
Send Inquiry
Product Description
WG Series Pulse Vacuum Autoclave
This series of WG Series Pulse Vacuum Autoclave utilizes saturated steam as its sterilization medium which releases a large amount of heat in the stage of condensation, and ensure the sterilizing environment in high temperature and at a certain humidity.
After a period of insulation in such status, sterilization purpose is achieved. The application of pulsating vacuum exhausting has successfully eliminated the temperature influence from cold air, and helping the sterilization items to be dried by means of vacuum and dehumidification between the jacketed layers.
Structure and Characteristic of the Wg Series Pulse Vacuum Autoclave
Body of the sterilizer.
Wg Series Pulse Vacuum Autoclave is designed and manufactured in accordance with GB150 *the Pressure Vessel. GB8599 The Techniseal Requirements of Large Steam sterilizer-Automatic Control Protocol". and TSG Rt004 the -Safety and Technology Specification for Fixed Monitor VesseNi and related insertion procedures.
The chamber in horizontal rectangular shape with double layer structure is made from S3008.
Door sealing:Pneumatic scaling:Both doors are interlocked and completely conform to the requirements of the specification with standard GMP authentication interface.
Sterilizer piping system: the pipeline is designed with the best configuration. All the spares are from qualified brands at home and abroad.
Sterilizer control system: SIEMENS PLC and SIEMENS touch screen, this system is easy to implement the program selection, parameter setting equipment operation, report processing and other functions. WG Series Pulse Vacuum Autoclave has prefect safety measures The FO value and the temperature time gives double guarantee for sterilization. A single parameter control is also available. WG Series Pulse Vacuum Autoclave has prefect sterilization records.
Main Parameters and Utilities of WG Series Pulse Vacuum Autoclave
|
Design Pressure |
0.245Mpa |
|
Working Pressure |
0.225Mpa |
|
Design Temperature |
139℃ |
|
Working Temperature |
105-134℃ |
|
Vacuum |
-0.09Mpa |
|
Temperature Equilibrium |
≤±1℃ |
|
Water Source Pressure |
0.15-0.3Mpa |
|
Compressed Air Pressure |
0.3-0.7Mpa |
|
Steam Pressure |
0.3-0.7Mpa |
|
Power |
AC380V, 50HZ |
Size & Utilities of WG Series Pulse Vacuum Autoclave
Note: 2436 represent the power of the built-in steam generator (optional)
|
Model |
Overall Size L×W×H(mm) |
Chamber Size L×W×H(mm) |
Steam Consumption(KG) |
Tap Water Consumption(KG) |
Power(KW) |
Net Weight(KG) |
|
WG-0.25 |
1100×1350×1900 |
800×600×600 |
18KG |
35KG |
2+24KW |
900KG |
|
WG-0.36 |
1300×1350×1900 |
1000×600×600 |
25KG |
40KG |
2+24KW |
1000KG |
|
WG-0.6 |
1500×1360×1950 |
1200×610×910 |
30KG |
45KG |
3+36KW |
1400KG |
|
WG-0.8 |
1800×1360×1950 |
1500×610×910 |
40KG |
50KG |
3KW |
1600KG |
|
WG-1.2 |
1750×1440×1950 |
1450×680×1180 |
48KG |
55KG |
4KW |
1800KG |
|
WG-1.5 |
2150×1440×1950 |
1850×680×1180 |
55KG |
60KG |
4KW |
2000KG |
|
WG-2.0 |
1950×1750×2200 |
1600×900×1400 |
65KG |
65KG |
4.5KW |
2500KG |
|
WG-2.5 |
2300×1750×2200 |
1950×900×1400 |
75KG |
75KG |
6KW |
3000KG |
|
WG-3.0 |
2700×1750×2200 |
2400×900×1400 |
90KG |
90KG |
8KW |
3500KG |
