Vertical Pressure Steam Sterilization
Use
The Vertical pressure steam sterilizations are assembled with heating system, microcomputer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effects, convenient of operation and energy conservation. Vertical pressure steam sterilizations are ideal equipments for clinics, scientific research institutes and other organizations to sterilizer surgical instruments, fabrics, glasses, culture media etc.
Characteristics of Vertical pressure steam sterilization
• Vertical pressure steam sterilization is fully automatically, no need for supervision, easy to use.
• Touch key, self-define of the sterilizing data.
• Hand wheel type of quick-open door structure, self inflating type seal, and with door safety lock system.
• Vertical pressure steam sterilization is equiped with electric pressure temperature controller, constant voltage and temperature can be automatically kept when the unit reach the setting parameter.
• Rapid sterilizing, only required 4~6 mins.
Technical Data of Vertical pressure steam sterilization
MODEL |
LS-28HD |
Technical Data |
|
Chamber volume |
28L φ270×500mm |
Working pressure |
0.22Mpa |
Working temperature |
134℃ |
Heat average |
≤±1℃ |
Timer range |
0-99mins |
Temperature adjust range |
105-134℃ |
Power |
2KW/AC220V 50HZ |
Overall dimension(mm) |
400×370×700 |
Transport dimension(mm) |
440×420×750 |
G.W/N.W |
26Kg/23Kg |
